  • 10pcs- 2 layer PCB

10pcs- 2 layer PCB

Starting at: $9.90


SPP01010PP
110g
Designer:Others

Please Choose:







The real dimension must be equal or smaller than the option.













*Upload the Gerber file must be packed into RAR orZIP format.





Qty: Unit(s)

    This service provide quick and high quality PCB fabrication experience for worldwide hobbyists. In this service, you can get 10 pcs of 2 layer PCB board with dimension up to 30 cm * 30 cm;
     Some other PCB qty for your prototyping can be found at:
     Elecrow will check all the related files as the order confirmed, and you order will be processed and shipped within 4-6 business days if all the files meets the requirements.

1. Gerber Files Required:

The following files would be needed for the 2-layers PCB production:
Top layer: pcbname.GTL
Bottom layer: pcbname.GBL
Solder Stop Mask top: pcbname.GTS
Solder Stop Mask Bottom: pcbname.GBS
Silk Top: pcbname.GTO
Silk Bottom: pcbname.GBO
NC Drill: pcbname.TXT
Mechanical layer : pcbname.GML
Note:
  • The Gerber file must be RS-274x format, The format of the drill file can be Excellon
  • Board outline must be included at least in one layer if there isn't GML/GKO layer.
  • All the holes will be plated by default, if you need some holes not plated, please name the non-plated holes as pcb.name-NPTH.txt and leave a comment;
  • For one layer PCB, If you need the solder mask on the top and bottom side, please order it as 2 layer PCB and leave a comment '1 layer PCB with solder mask both side".

  • 2. Specifications

    Multi Layers 1-2-4
    PCB Material  FR-4
    Available Color Green, Red, Yellow, Blue, White, Black
    Silk Screen  White, Black (For White Solder Mask only)
    Maximum Size 45cm X 120cm
    Minimum Qty 5pcs
    Board Thickness 0.6mm,0.8mm, 1.0mm, 1.2mm, 1.6mm
    Thickness Tolerance (t≥1.0mm) ± 10%
    Thickness Tolerance (t<1.0mm) ± 0.1mm
    Insulation Layer Thickness  0.075mm--5.00mm
    Minimum PCB track  6mil (Recommend >8mil)
    Minimum Track/Vias Space   6mil  (Recommend >8mil)
    Minimum pads Space  8mil
    Minimum silkscreen text size  32mil
    Out Layer Copper Thickness  1oz(35um)
    Inner Layer Copper Thickness  1oz(35um)
    Drilling Hole (Mechanical) 0.3mm—6.35mm
    Finish Hole (Mechanical) 0.8mm—6.35mm
    Drill Diameter Tolerance (unplated) 0.05mm
    Drill Diameter Tolerance (plated) 0.1mm
    Outline Tolerance (Mechanical)

    ±0.20mm

    Aspect Ratio 8:1
    Solder Mask Type Photosensitive ink
    SMT min Solder Mask Width 0.2mm
    Min Solder Mask Clearance 0.2mm
    Solder Mask Thickness 15um
    Surface Finish HASL, HASL (Lead Free), ENIG+$14.9.

    3. Wiki & External links
