Crowtail- Current Sensor 2.0

SKU
CT0029CS
In stock
weight
6.0000
$3.98
-
+
Overview
Crowtail- Current Sensor
This current sensor gives precise current measurement for both AC and DC signals. These are good sensors for metering and measuring overall power consumption of systems. The ACS712 current sensor measures up to 20A of DC or AC current. The ACS712 Low Current Sensor Breakout outputs an analog voltage that varies linearly with sensed current. To calibrate, first set the output offset to the desired level (with zero current on the sense lines, read output with a DVM). Then with a known current input (a 100mA limited supply works well for this), set the output deflection with the gain pot. Sensitivity is then calculated as (Vref - Vdeflect)/(current input).

Part List

  • 1 X Crowtail- Current Sensor
  • 1 X Crowtail 4 Pin Cable
  • Dimensions(mm):40.0(L)x20.0(W)x6.8(H)

Wiki & External links
