Crowtail- Dual Coil Latching Relay Module 2.0

Rating:
0% of 100
SKU
CRT01665R
Weight
16 g
Availability
In stock
$5.20
-
+
This is a dual-channel latching relay,it can keep the original state from changing in the event of a power failure. If you need to change the state, only need to rise or falling edge. Since the power supply can be cut off without changing the operating state,so that the module is specifically designed for low power consumption circuit design.
It is widely used in remote control, telemetry, communication, automatic control, electromechanical integration and power electronic equipment, is one of the most important control components

Features

  • 2 Form C contact, Polarized relay.
  • High sensitivity 150mW.
  • Fits standard 16 pin IC socket.
  • High switching capacity 60W,125VA.
  • Epoxy sealed for automatic wave soldering and cleaning.

Specifications

  • Operating voltage: 5v
  • Set/Reset Voltage (Max): 4.0 VDC
  • Switching Voltage (Max): 35 VAC/ 35 VDC
  • Switching Current (Max): 3A
  • Set Time (Latching): 4.5 (max) ms
  • Reset Time (Latching): 3.5 (max) ms
  • Dimensions(mm):50.0(L)x35.0(W)x14.3(H)

Package list

  • Crowtail- Dual Coil Latching Relay Module x1
  • 4 pin Crowtail cable x1
