Elecrow RR101 10.1 Inch 1280x800 Portable Monitor Metal Shell IPS Screen with Touch Function for Raspberry Pi All-In-One PC

Rating:
0% of 100
0  Reviews / Write a review
SKU
DRD16013D
Weight
1600 g
Availability
In stock
$110.90
-
+
With this product, you earn 111 reward points.
Add To Wish List Compare this Product
The Elecrow RR101 is 10.1inch IPS LCD Monitor that has a metal shell and loudspeaker, which could connect to the Raspberry Pi board at the back of the screen. Besides, it uses two in one power, the Raspberry Pi can be powered by the screen. Thus, reduce unnecessary wires and keep you a clean desktop.

product_name
The 10.1 inch IPS LCD Monitor has a high resolution of 1280x800 pixels and can be controlled by touching and remote control. With the keys on the monitor back, you can choose to control the screen by pressing the key or using the remote control-adjust its contrast or color. The monitor supports multiple video input interfaces such as HDMI-compatible interface, VGA, and AV, and also supports audio.
product_name

The monitor is widely used in industrial automation, intelligent computer, security, video microscopy, industrial equipment dedicated display, car reversing, etc
Tips for Raspberry Pi:
Step 1: Open the terminal and d
ownload the driver on RPI
Run:
git clone https://github.com/Elecrow-keen/Elecrow-LCD101.git
Step 2: Install driver
Run:
'''sh setup.sh''' # To install the eGTouch driver. '''sh setup.sh uninstall''' # To remove the eGTouch driver.

Tips for Windows OS:
Driver link:Github link

Features

  • Supports multiple video input interfaces: HDMI-compatible, VGA, AV, and BNC
  • High resolution of 1280x800 pixels
  • Support key operation and remote control
  • Suitable for Windows system PC and Raspberry Pi
  • The IPS screen features a wide visual angle, fast response speed, and accurate color rendition
  • Equipped with reserved fixing holes for control boards-suitable for Raspberry Pi 3 Model B, 2model B, and support audio speaker
  • High sensitivity, strong anti-jamming

Specifications

  • Model: RR101
  • Color：Black.
  • Screen size: 21.8 (L) x 13.6 (W)cm
  • Appearance Size:25(L)X16.8X3.5cm
  • Package size: 31 (L) x 25 (W) x 7 (H) cm
  • Item Weight:1600g.
  • Resolution:1280 x 800.
  • Wide viewing angle: 85/85/85/85 .
  • Shell: metal.
  • Input voltage: 12v.
  • Contrast ratio: 500:1
  • Light intensity: 300

Package list

  • 10.1Inch HDMI-compatible IPS LCD Monitor x1
  • 12V/2A power adapter x1
  • Remote control x1
  • HDMI-compatible cable x1
  • USB A to USB A cable x1
  • USB A to Micro USB cable x1
  • AcRylic Board x1
  • Plastic Screws x4
  • Plastic Standoff x4
  • Plastic Nuts x4
  • Screws (M4*10mm) x4

Wiki & External links

Size Product Name Resolution Display Tec Display Port Touch Panel Type Screen Dimension VESA Audio Output Camera Microphone Multi-language Menu Backlight Buttom Device Support
8
inch		 Elecrow SH080T 8 Inch Mini HDMI Portable LCD Display 1280x800 Resolution Monitor  1280x800  IPS  HDMI&USB  Capacitive  176.64×110.4  √ Earphone & Speaker  ×  ×  × × Raspberry Pi, PC etc.
10.1
inch		 SF101T 10.1 Inch Touchscreen 1920x1080 IPS Monitor for Raspberry Pi 1920x1080 IPS HDMI&VGA Capacitive 255x164 √ Earphone & Speaker × × × × Raspberry Pi, PC etc.
ELECROW SQ101 10.1 Inch 2K IPS 2560x1600 Monitor with Built-in Speaker for Raspberry Pi PS4 XBOX Windows 2560x1600 IPS HDMI&USB × 246x175x25mm √ Earphone & Speaker × × × × Raspberry Pi, PC etc.
Elecrow SF101 10.1 Inch 1920x1080 Display HDMI VGA IPS PS3 PS4 Gaming Screen with Build-In Speakers for Raspberry Pi/ XBOX/ Windows 7/8/10 1920x1080 IPS HDMI&VGA × 255x164X28mm √ Speaker × × × × Raspberry Pi, PC etc.
Elecrow RR101 10.1 Inch 1280x800 Portable Monitor Metal Shell IPS Screen with Touch Function for Raspberry Pi All-In-One PC 1280x800 IPS

HDMI&VGA&

USB&AV&BNC

 Capacitive 243x163x40mm × Earphone & Speaker × × × × Raspberry Pi, PC etc.
SF101R 10.1 Inch Portable HD Display for Raspberry Pi 3 1024x600 IPS

HDMI&USB&

VGA&TV&AV

 × 233.8mmx138.5mm × Earphone & Speaker × × × × Raspberry Pi, PC etc.
11.6
inch		 SF116 11.6 Inch 1920x1080 HDMI 1080P LED Display for Raspberry Pi 1920x1080 TFT HDMI&VGA × 288x185x25mm × Speaker × × × × Raspberry Pi, PC etc.
13.3
inch		 Elecrow MQ133 13.3 Inch 2K IPS 2560x1440 HD Display Dual Mini HDMI Port for Laptop PC PS4 WiiU Xbox Raspberry Pi 4B/3B+/3B 2560x1440 IPS Dual HDMI&USB × 318.3x198.4x11.5mm × Earphone & Speaker × × × × Raspberry Pi, PC etc.
ELECROW SF133 13.3 Inch IPS 1920X1080 Monitor Dual HDMI PortablePS3 PS4 Gaming Screen with Build-In Speakers for Raspberry Pi/ XBOX/ Windows 7/8/10 1920x1080 IPS Dual HDMI&USB × 323x205x15mm × Earphone & Speaker × × × × Raspberry Pi, PC etc.
SF133M 13.3 inch 1920 x 1080 HDMI Portable Display for Raspberry Pi/ PS4/ XBOX/ NS 1920x1080 IPS Dual HDMI&Type-C × 320x200x8mm × Earphone & Speaker × × × × Raspberry Pi, PC etc.
15.6
inch		 15.6" Touchscreen Portable Monitor 1920x1080 HDMI with Laptop Stand 1920x1081 IPS HDMI&USB Capacitive 344.16x193.59 mm × Speaker × × × × Raspberry Pi, PC etc.
