[ESP32-S3 Controller] Dual-core 240MHz, 8MB PSRAM + 16MB Flash, ample computing power
[4.3-inch Color Screen] 480x272 resolution, 65K colors, exquisite picture quality
[Resistive Touch] Sensitive and precise, convenient human-computer interaction
[Wireless Connectivity] 2.4GHz Wi-Fi + Bluetooth 5.0, easy access to the IoT
[Rich Interfaces] Type-C, TF card slot, serial port, SPI, UART, strong expandability
[Reliable Quality] Passed rigorous aging tests and other multiple tests, supports long-term stable operation
[Out-of-the-Box Use] Provides sample programs and technical documentation, and quickly gets started developing features
This 4.3-inch ESP32-S3 display development board perfectly combines a high-performance ESP32-S3 dual-core processor with a 480x272 color screen. The main controller uses an Xtensa LX7 dual-core processor with a clock speed of up to 240MHz, and includes 8MB PSRAM and 16MB Flash memory. It supports 2.4GHz Wi-Fi and Bluetooth 5.0 wireless communication, providing ample computing power and expandability for IoT and embedded HMI applications.
The screen is a 4.3-inch TN color display, supporting RGB565 color display and resistive touch, offering rich colors and convenient human-machine interaction. The board features a Type-C interface, Micro TF card slot, serial port, SPI, UART, and other expansion interfaces, with ample GPIO pins for easy connection to various peripherals. It provides a complete set of sample programs and low-level driver support. The product has undergone rigorous aging tests and supports long-term stable operation, making it an ideal choice for smart home central control, industrial control terminals, IoT nodes, and other projects.
OEM customized requests can be discussed(based on MOQ), you can contact us at service@elecrow.com.
Hardware Overview
|
Interface Name |
Function Description |
|
① ESP32-S3 |
Display module main control, control board peripheral and external peripheral. |
|
② MicroSD card slot |
A MicroSD card is inserted to expand the storage space for storing large data such as characters, pictures, and audio files. |
|
③UART0 |
1.25mm 4P connector.It can be used for serial debugging, downloading, and communication. An external USB to serial port module is required. |
|
④ BOOT Key |
Used to enter download mode or key test. Press and hold this button to power on and release it to enter the download mode. Alternatively, press and hold this button and then press the RESET button to release the RESET button and then release this button to enter the download mode. When you do not need to enter the download mode, this button can be used as a common button. |
|
⑤ Type-C Interface |
Used for module power supply and download programs. This interface is connected to the one-click download circuit on the module, which can automatically enter the download mode (without pressing the BOOT key). |
|
⑥ RESET Key |
Used for ESP32 master control and LCD reset, level reset after pressing. |
|
⑦ Expand Pin |
1.25mm 4P socket, leading out GPIO17/GPIO18 pins. |
|
⑧ UART1 & USB |
1.25mm 4P socket, leading out four free pins: GPIO17, GPIO18, GPIO19 and GPIO20. GPIO17 and GPIO18 can be used for UART1, while GPIO19 and GPIO20 are compatible with the USB protocol. |
|
⑨ SPI Interface |
1.25mm 4P socket, designed for connecting external SPI communication devices. This SPI interface is shared with the resistive touch screen and SD card, and can also be used as GPIO. |
|
ESP32 Module |
|
|
Chip |
ESP32-S3 (N16R8) |
|
CPU |
Xtensa LX7 32-bit dual-core processor |
|
Frequency |
240MHz(Max) |
|
Memory |
384KB ROM+512KB SRAM+16KB RTC SRAM+8M internal OPI PSRAM+16M external SPI Flash |
|
Wi-Fi |
2.4GHz, 802.11b/g/n mode |
|
Bluetooth |
Bluetooth V5.0 BR/EDR and Bluetooth LE standard |
|
Screen |
|
|
Panel Size |
4.3 inch |
|
Panel Type |
TN TFT |
|
Touch Screen Type |
Resistive touch screen |
|
Resolution |
480x272 |
|
Active Area |
95.04(W)x53.86(H)(mm) |
|
Number of Pixels |
65K(RGB565) |
|
Display Driver IC |
ILI6485 |
|
Screen interface |
RGB565-16Bit |
|
View Angle |
6 ’CLOCK |
|
Brightness(TYP) |
350 cd/m2 |
|
Backlight Type |
White LED*7 |
|
Touch Driver IC |
XPT2046 |
|
Communication Interface |
SPI |
|
Pixel Size |
0.153(H)x0.153(mm) |
|
Other |
|
|
Working Voltage |
5.0V |
|
Total current (typical value) |
190mA |
|
Total power consumption (typical value) |
0.95W |
|
Operation Temperature |
-20~60(℃) |
|
Storage temperature |
-30~70(℃) |
|
Module Size |
123(W)x74(H)x8.7(D) |
|
Net Weight |
95g |
|
Onboard Equipment |
ESP32 Connect Pins |
Pin Description of Onboard Equipment |
|
LCD |
IO40 |
Data Enable Control Pin |
|
IO41 |
Vertical Sync Signal Control Pin |
|
|
IO39 |
Horizontal Sync Signal Control Pin |
|
|
IO42 |
Pixel Clock Control Pin |
|
|
IO42/48/47/21/14 |
5-bit RED Data Pin |
|
|
IO5/6/7/15/16/4 |
6-bit GREEN Data Pin |
|
|
IO8/3/46/9/1 |
5-bit BLUE Data Pin |
|
|
RTP |
IO12 |
Resistive Touch Screen SPI Bus Clock Control Pin |
|
IO13 |
Resistive Touch Screen SPI Bus Data Write Control Pin |
|
|
IO11 |
Resistive Touch Screen SPI Bus Data Read Control Pin |
|
|
IO38 |
Resistive Touch Screen SPI Bus Chip Select Control Pin |
|
|
IO18 |
Resistive Touch Screen SPI Bus Interrupt Control Pin |
|
|
MicroSD |
IO10 |
SD Card SPI Bus Chip Select Control Pin |
|
IO11 |
SD Card SPI Bus Data Read Control Pin |
|
|
IO13 |
SD Card SPI Bus Data Write Control Pin |
|
|
IO12 |
SD Card SPI Bus Clock Control Pin |
|
|
KEY |
IO0 |
Download Mode Selection Button (Press this button to power on, then release to enter download mode) |
|
EN |
ESP32-S3 Reset Button, Active Low Reset |
|
|
UART0 |
RXD0(IO43) |
ESP32-S3 UART0 Transmit Signal Pin |
|
TXD0(IO44) |
ESP32-S3 UART0 Receive Signal Pin |
|
|
SPI |
IO19 |
SPI Bus Chip Select Control Pin |
|
IO11 |
SPI Bus Data Read Control Pin |
|
|
IO13 |
SPI Bus Data Write Control Pin |
|
|
IO12 |
SPI Bus Clock Control Pin |
|
|
Expand pin |
IO18 |
It can be used as GPIO when the touch and SD card functions are not in use. |
|
IO17 |
It can be used as GPIO when the touch and SD card functions are not in use. |
|
|
USB |
IO19 |
USB Bus Differential Signal Data Line (Negative) |
|
IO20 |
USB Bus Differential Signal Data Line (Positive) |
|
|
UART1 |
IO17 |
ESP32-S3 UART1 Transmit Signal Pin |
|
IO18 |
ESP32-S3 UART1 Receive Signal Pin |
