Surface Mount Misaligned Pin Header | 2.54mm Pitch | 4 Pins (10pcs-1pack)

Description

This 2.54mm pitch single-row 4-pin vertical surface mount header uses an SMD staggered lead package (1x4P) and is designed for automated SMT assembly processes, allowing for efficient integration onto PCBs. The contacts are made of high-quality brass with a tin-plated finish, offering both excellent conductivity and solderability, and adaptability to various operating environments. The product has a rated current of 3A, a 3mm pin length, and a 2.5mm molding height, resulting in a compact and stable structure. It can be flexibly paired with standard female headers or wire harness terminals to achieve board-to-board or board-to-wire signal transmission and power connections. It is widely used in consumer electronics, small industrial control modules, and other conventional electronic equipment applications.

Specification

Package List

• 1x Surface Mount 4Pin Header

Wiki & External links

• Specification
