ThinkNode G4 Wi-Fi HaLow Gateway Support Wi-Fi/Wi-Fi HaLow/Ethernet Connections | Supports AP/STA/Mesh, etc

Description

What is WiFi Halow?

Wi-Fi HaLow (based on the IEEE 802.11ah) is a low-power, long-range wireless communication technology designed by the Wi-Fi Alliance specifically for IoT scenarios. Compared to traditional Wi-Fi technology, it operates in the Sub-1 GHz unlicensed frequency band (mainly the 900MHz band). This frequency gives it stronger diffraction capabilities and penetration, enabling it to effectively penetrate buildings, vegetation, and other obstacles, thus overcoming the inherent limitations of traditional Wi-Fi in terms of coverage and environmental penetration.

The ThinkNode G4 Wi-Fi HaLow gateway is a long-range, high-speed wireless communication device designed for IoT applications. Based on IEEE 802.11ah (Wi-Fi HaLow) technology, it operates in the Sub-1GHz unlicensed frequency band. Theoretically, it can achieve a transmission distance of over 1 kilometer and supports data transmission rates up to 32 Mbps, perfectly filling the technological gaps of traditional Wi-Fi's short coverage and LoRa's low speeds.

The gateway is equipped with a high-performance MCU and advanced RF front-end, supporting dual-band design for both Wi-Fi HaLow and 2.4GHz Wi-Fi, and provides an Ethernet interface for flexible integration into existing network infrastructure. Configuration and OTA upgrades can be completed through a simple Web UI. It supports various networking methods such as AP, STA, and Mesh, and a single gateway can connect to a large number of devices, making it an ideal choice for smart manufacturing, smart cities, and smart agriculture scenarios.

Designed and manufactured by Elecrow, customized requests can be discussed(based on MOQ), you can contact us at service@elecrow.com.

Hardware Overview

Feature

• Long-distance, high-speed transmission: Utilizing Wi-Fi HaLow technology, the theoretical line-of-sight distance can exceed 1 kilometer, maintaining a rate of 150 Kbps even at extreme distances, and reaching up to 32 Mbps at close range, balancing coverage and data throughput.
• Strong penetration and low power consumption: Operating in the Sub-1GHz band, it can effectively penetrate obstacles such as buildings and vegetation; its low-power design is suitable for long-term deployment in outdoor and industrial environments.
• Dual-band flexible networking: Supports dual-band design of Wi-Fi HaLow and 2.4GHz Wi-Fi, and is equipped with an Ethernet interface, supporting various networking methods such as AP, STA, and Mesh, flexibly adapting to the network architecture requirements of different scenarios.
• Massive device access: A single gateway can support a large number of terminal devices connecting simultaneously, with an access capacity more than 4 times that of traditional Wi-Fi access points, meeting the needs of large-scale IoT node deployment.
• Wide-temperature industrial-grade design: Operating temperature range of -20℃ to 70℃, adaptable to harsh outdoor and industrial environments, ensuring long-term stable operation of the device.
• Easy installation and maintenance: The lightweight and stylish wall-mounted design makes installation simple; it supports Web UI configuration and OTA remote upgrades, reducing on-site operation and maintenance costs.

Scenarios

• Remote camera monitoring
• WiFi-HaLow gateway
• Industrial automation control
• Asset management and tracking
• Smart home
• Smart city
• Wi-Fi/Ethernet/Wi-Fi-HaLow extension and bridging
• Rural internet access
• LAN construction
• Network blind spot coverage

Who needs this?

Makers, embedded/IoT engineers, and people in fields such as smart agriculture, security monitoring, smart cities, industrial IoT, and photovoltaic and water conservancy.

Specification

Why choose us?

As an industry-leading equipment manufacturer, we rely on our independently developed core technology and the production strength of our factories to ensure that every product has precise quality control from design to manufacturing, and is both reliable and innovative. We provide online customer service support to answer your questions at any time, making the whole process worry-free. At the same time, we provide customized solutions to accurately meet your personalized needs. Choosing Elecrow means choosing safety, efficiency and professionalism.

Package List

• 1x ThinkNode G4 Wi-Fi HaLow Gateway
• 1x Wi-Fi HaLow Antenna
• 1x 2.4GHz Antenna
• 1x USB-C Cable(1m)
• 1x Base

Wiki & External links

• Wiki
• User Manual
