PA Conveyor

Conveyor belt for transporting workpieces has limited space. Dimensions as shown in the attached picture.

PA Conveyor

  • thumbnail-img
  • thumbnail-img
  • thumbnail-img
  • thumbnail-img
  • thumbnail-img


Story

It is a device to continuously move workpieces. It is driven by a motor that causes the belt to rotate. This makes production and transportation in industrial plants faster, more efficients.

Working and benefits

Continuous Movement : The movement of materoals or workpieces at a speed that allows them to be found.

Description : The reason for mentioning speed and keeping up with news.

Work and Labor : Reduces the need for a large number of moving workers.

Reduce costs : Helps save on production and operating costs.

Reduce risks : Reduces the chance of accidents during handling.

Industrial use

Manufacturing industry : such as electronic parts and automotive parts

Food industry : such as bread, fruit, or food packaging

Other industries : logistics warehousing,distribution centers.



Schematic and Layout
  • Conveyor

    Assem-CONVEYOR-600-001_564076317690acca9c8b17.zip
    Download(1)
CAD-Custom parts and enclosures
  • Belt Conveyor

    Assem-CONVEYOR-600-000_1244456494690acbda96138.STEP
    Download(1)
