Philips Hue Ambiance Clone – DIY RGB LED Controller

Recreate a Philips Hue-style smart lamp using ESP32, RGB LEDs, and separate warm/cool white strips. Fully controllable via IR, rotary encoder, and Home Assistant – with effects, brightness, and presets powered by ESPHome.

Philips Hue Ambiance Clone – DIY RGB LED Controller

  • thumbnail-img
  • thumbnail-img


Tools, APP Software Used etc.

  • Home Assistant

    Open Source
  • EspHome

Story



This DIY project replicates the core features of a Philips Hue Ambiance lamp using an ESP32 and a custom PCB. It supports RGB animations with WS2812 LEDs as well as separate control of warm white and cool white LED strips. An IR receiver and rotary encoder input allow physical control options alongside full smart home integration.

Powered by ESPHome, the controller works seamlessly with Home Assistant. You can set color effects, adjust brightness, blend between warm and cool white, or trigger scenes via remote, automation, or voice. All firmware is open and configurable via YAML.



📌 Highlights:

✅ RGB and dual white LED control (warm & cool white)
✅ WS2812 / Neopixel compatible
✅ ESP32 with ESPHome firmware
✅ Infrared remote control input
✅ Rotary encoder support
✅ Full Home Assistant integration
✅ OTA updates via WiFi
✅ Configurable effects, brightness & color presets
✅ 3D-printed case files and full documentation available



Video


https://youtu.be/yIegSiVpkys



📌Build instructions and firmware:

👉 smarthomeyourself.de/philips-hue-ambiance-clone

Code
  • ESPHome Code

    https://smarthomeyourself.de/hc_downloads/hue_ambiance_clone_esphome.txt
    View
CAD-Custom parts and enclosures

Philips Hue Ambiance Clone – DIY RGB LED Controller

Recreate a Philips Hue-style smart lamp using ESP32, RGB LEDs, and separate warm/cool white strips. Fully controllable via IR, rotary encoder, and Home Assistant – with effects, brightness, and presets powered by ESPHome.
